Claro 10.1 Loudspeaker

Claro 10.1 Loudspeaker

R 98,800.00

The Claro 10.1 is a very special package. If you are looking for a small loudspeaker with the punch of a large speaker, this will surprise you. The 38 mm tractrix loaded ring radiator tweeter is at the centre of symmetrically positioned 5” mid woofers. The light cones of these drivers translate into impressive speed and detail from what seems to be a single point source. The powerful 10” side firing sub-woofer (not a passive radiator) takes over from the low pass roll off of the midrange drivers. The woofers can fire into boundary walls for bass emphasis or can be positioned to fire towards each other for tight defined bass. Off axis response has been optimised to allow wide distance between the loudspeakers if the interior of your room requires the speakers to be close to your walls. A very special & capable loudspeaker. It is a true 4 ohm loudspeaker, so ensure your amplifier can cope with a four ohm load.

Specifications

  • Dimensions: 1090x172x395 (HxWxD)
  • Weight: 46 Kg’s each
  • Impedance: 4 ohm
  • Frequency Range: 25 Hz – 22 KHz (+/- 3 dB)
  • Power Handling: 180 watt
  • Drivers: 2 x active 5” mid-woofer, 38mm ring radiator tweeter, 10” sub woofer
  • Low Frequency Alignment: Mid-bass = sealed / 10” sub-woofer = Bass reflex
  • High Frequency Loading: Tractrix horn
  • Crossover Point: 300 / 4000 Hz
  • Efficiency: 89 dB (1 watt @ 1 meter)
  • Filter Configuration: Low Pass 1st order / mid 3rd order / High Pass 3rd order
